Type:DIN F4 gate valve

Fig No:BKGVM-01

Size: DN40-2000

Working Pressure: PN10,PN16

Suitable temperature: 0~100 Celsius

Standard:

(1)Design and manufacture: DIN3352 F4,F5, BS5163, BS5150, , EN593, GB/T12238

(2)End connection: DIN2543-2550, EN1092, AS2129, ISO 5211

(3)Wall thickness: APBS1868

(4)Face to face (end to end): EN 558, DIN3202, ISO5752, BS5155

(5)Inspection and test: EN12266-1, BS6755, ISO5208

Materialfor main parts:

(1)Body: Cast Iron or Ductile Iron

(2)Disc: Ductile Iron

(3)Stem: SS416, SS410, SS304, SS316,SS431

(4)Seat: Bronze,Cr13,SS304,Brass,SS316

Coating: Fusion bonded epoxy power coated

Connection type: Flanged type, Push-on type, Mechanical Joint type, Plain ends type

Sealing: Soft sealing or metal-to-metal seat, Flexible graphite

Operation: Manual, Pheunatic, Electric, Hydraulic and Pnewmatic-Hydraul

Appropriate medium: Air, water, sewage, steam, coal gas, oil

Packaging: Export polywood cases, or as per customers' requirements

Delivery Time: 20-45 days after order conformed

Payment: By T/T or L/C

Application: Fresh water, sewage, sea water
